Texturized Filter Cloth
PostTime:2010-8-12  Text 〖 B M S 〗  Reads:9525   [Close]

Texturized Fiberglass Filter Cloth

E-glass Fiberglass Texturized Filter Cloth

Product Code
EWTF400
EWTF450
EWTF500
EWTF550/A
EWTF550/B
EWTF650
EWTF800
Weave
1/3Twill
1/3Twill
1/3Twill
1/3Twill
1/3Twill
Weft double
Weft double
Count
19×12.5
19×10
18×13
18×12
18×12
20×20
20×18
Mass (g/m2)
≥400
≥420
≥470
≥510
≥510
≥600
≥750
Tensile Strength
(N/25mm)
Warp
≥1750
≥1750
≥2200
≥2200
≥2200
≥2400
≥2400
Weft
≥1050
≥1000
≥1100
≥2000
≥1500
≥1700
≥2100
Air permeability
(cm3/cm2.s)
20~40
30~55
15~35
15~35
15~35
15~35
15~35

C-glass Fiberglass Texturized Filter Cloth

Product Code
CWTF450
CWTF550
CWTF700
Weave
Twill
Weft double
Weft double
Count
20×14
20×20
20×18
Mass(g/m2)
≥450
≥530
≥670
Tensile Strength
(N/25mm)
Warp
≥1700
≥1700
≥1700
Weft
≥900
≥1200
≥1500
Air permeability
(cm3/cm2.s)
20~40
20~40
20~40
